Avail 3

$850 Original price $900

Whether you're seeking epic solo adventures or joining group road rides, the Avail is the perfect companion. Designed to be lightweight and comfortable, it provides the ultimate riding experience, empowering you to conquer your rides with ease and enjoy every moment on the road.

Key Performance Factors

Built for Endurance

Lightweight and balanced, the modern endurance geometry delivers a smooth all-day ride experience.

Power Transfer

Equipped with OverDrive and PowerCore technologies, this efficient frameset offers superior stiffness without compromising compliance.

Adaptable Comfort

The Avail tackles the roads less traveled with larger-size tire compatibility and a D-Fuse seatpost to soak up road vibrations.

Techs & Features

ALUXX Aluminum Technology
Compact Road Design
D-Fuse Seatpost
OverDrive

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XS
      153 cm5’0”  to 162 cm5’4”
  • S
      158 cm5’2”  to 169 cm5’7”
  • M
      165 cm5’5”  to 174 cm5’9”
  • L
      171 cm5’7”  to 182 cm6’0”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
 XSSML
A Seat Tube Length (mm) (inch)43016.946518.350019.753521.1
B Seat Tube Angle (degrees)75.0°74.5°74.0°74.0°
C Top Tube Length (mm) (inch)51520.352520.754021.355521.9
D Head Tube Length (mm) (inch)1355.31505.91706.71907.5
E Head Tube Angle (degrees)70.5°72.0°72.0°72.0°
F Fork Rake (mm) (inch)451.8451.8451.8451.8
G Trail (mm) (inch)732.963.52.563.52.563.52.5
H Wheelbase (mm) (inch)99839.399039100039.4101640
I Chain Stay Length (mm) (inch)42016.542016.542016.542016.5
J Bottom Bracket Drop (mm) (inch)702.8702.8702.8702.8
K Stack (mm) (inch)53020.955021.756922.458823.1
L Reach (mm) (inch)37214.637214.637714.838615.2
M Stand Over Height (mm) (inch)6872771628.274429.377230.4
N Handlebar Width (mm) (inch)3801540015.740015.742016.5
O Stem Length (mm) (inch)702.8803.1903.5903.5
P Crank Length (mm) (inch)1656.51706.71706.7172.56.8
Q Wheel Size 700C700C700C700C

See how other people Liv Beyond

Specs
  • Sizes
    XXS, XS, S, M, L
  • Colors
    Misty Lilac
  • Frame
    ALUXX-grade aluminum
  • Fork
    Advanced-grade composite, full-composite OverDrive steerer
  • Shock
    N/A
  • Handlebar
    Liv Connect, 31.8mm XXS: 380mm, XS: 380mm, S: 400mm, M: 400mm, L: 420mm
  • Grips
    Liv Bar Tape
  • Stem
    Liv Sport XXS: 80mm, XS: 80mm, S: 90mm, M: 100mm, L: 100mm
  • Seatpost
    Giant D-Fuse, alloy XXS: 300mm, XS: 300mm, S: 300mm, M: 350mm, L: 350mm
  • Saddle
    Liv Approach
  • Pedals
    N/A
  • Shifters
    Shimano Claris
  • Front Derailleur
    Shimano Claris
  • Rear Derailleur
    Shimano Claris
  • Brakes
    Tektro TK-B177
  • Brake Levers
    Shimano Claris
  • Cassette
    Shimano CS-HG50, 8-speed, 11x34
  • Chain
    KMC XZ83
  • Crankset
    FSA Tempo, 34/50 XXS: 165mm, XS: 165mm, S: 170mm, M: 170mm, L: 172.5mm
  • Bottom Bracket
    cartridge
  • Rims
    Giant S-R3 Disc wheelset
  • Hubs
    Giant alloy
  • Spokes
    stainless
  • Tires
    CST Sprint, 700x28c
  • Extras
    28mm max tire size
  • Max Tire Clearance
    28mm
  • Weight
    9.57 kg (21 lbs 02 oz) - Size (S)

*All specifications and prices listed are subject to change without notice.
Actual weight may vary due to manufacturing tolerances, color variations, frame size and variability in production components.
