Langma Advanced
SL Disc 0

NT$280,000

我適合的尺寸

分享

Already favored by climbing addicts and WorldTour racers, the all-new Langma Advanced SL Disc is redesigned to be lighter, stiffer, and ready to throw down on race day.

重點特色資訊

Featherweight efficiency

The heart of the Langma is an ultra-light Advanced SL-Grade Composite frameset—which we’ve rebuilt with longer, more continuous pieces of carbon fiber for a stiffer bike that’s 60 grams lighter.* So you get a responsive ride that accelerates immediately, skims over rough roads and surges up climbs. And a translucent frame coating shows off this carbon construction, making the Langma look as fast as it feels. * Compared to the first-generation Langma Advanced SL frameset

Intuitive handling

We’ve re-engineered the Langma fork for 50% more lateral stiffness,* for precise handling and responsiveness. An oversized headset and all-new Liv Contact SLR handlebar boost control without sacrificing aerodynamics. Integrated, flat-mount disc brakes deliver stopping confidence in varied conditions. The Langma even accommodates tires up to 32mm for extra grip in the corners and cobbles. * Compared to the first-generation Langma Advanced SL fork

Aero advantage

Updated truncated ellipse tubing reduces wind drag at a wider range of yaw angles, gaining you precious seconds in flats, descents, and headwinds. Our relentless testing and refinement have also inspired the development of the new fully-carbon Variant SLR seatpost. Plus, the all-new CADEX 36 Disc WheelSystem with side-drag control lets you stash more watts for the sprint finish.

科技新知

COMPACT ROAD DESIGN 壓縮式車架設計
整合式座管束子
第二代加大車首強化設計
Power Core 整合式加大五通設計
Tubeless System 無內胎外胎系統
MEGADRIVE加大管件強化設計
Variant SLR Seatpost
Hookless Rim Design

車架幾何

車架幾何僅供參考,請洽詢問捷安特授權門市;尺寸會因為不同國家而異。

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XXS
      145 cm4’9”  to 157 cm5’2”
  • XS
      152 cm5’0”  to 163 cm5’4”
  • S
      158 cm5’2”  to 169 cm5’7”
  • M
      164 cm5’5”  to 176 cm5’9”
  • L
      170 cm5’7”  to 183 cm6’0”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  XXSXSSML
A座(立)管長 (mm) (inch)39015.442016.545017.748018.951020.1
B座(立)管角度 (degrees)75.0°75.0°74.5°74.0°73.5°
C上管長度 (mm) (inch)49819.65082052420.654021.355521.9
D頭管長度 (mm) (inch)1054.11204.71355.31556.11756.9
E頭管角度 (degrees)70.0°71.0°72.0°72.5°72.5°
F前叉 (mm) (inch)491.9491.9491.9491.9491.9
GTrail (mm) (inch)74.32.967.82.661.42.458.22.358.22.3
H前後輪距 (mm) (inch)97038.297338.397738.598438.799639.2
I後下叉長度 (mm) (inch)40515.940515.940515.940515.940515.9
J五通下降高度 (mm) (inch)722.8722.8702.8702.8672.6
K頭碗至五通高度 (mm) (inch)49919.651720.453220.955321.856922.4
L頭碗至五通長度 (mm) (inch)36414.337014.637714.83821538615.2
M上管至地面高度 (mm) (inch)68026.870027.673028.776029.979031.1
N把手寬 (mm) (inch)36014.236014.23801540015.742016.5
O龍頭長度 (mm) (inch)803.1803.1903.51003.91104.3
P曲柄長度 (mm) (inch)1656.51656.51706.71706.7172.56.8
Q輪組尺寸 700C700C700C700C700C
產品規格
  • 尺寸
    XXS, XS, S, M, L
  • 顏色
    Ultra Navy/Chrome
  • 車架
    Advanced SL-Grade Composite, 12x142mm thru-axle, disc
  • 前叉
    Advanced SL-Grade Composite, full-composite OverDrive 2 steerer, 12x100mm, disc
  • 避震器
    N/A
  • 車把手
    Liv Contact SLR XXS:36cm, XS:36cm, S:38cm, M:40cm, L:42cm
  • 把手帶/套
    Liv All Condition
  • 豎桿
    Giant Contact SLR XXS:80mm, XS:80mm, S:90mm, M:100mm, L:110mm
  • 座桿
    Giant Variant SLR, composite XXS:357mm, XS:357mm, S:357mm, M:357mm, L:357mm
  • 坐墊
    Liv Alacra SLR
  • 踏板
    N/A
  • 變速把手
    Shimano Dura-Ace Di2 ST-R9270
  • 前變速器
    Shimano Dura-Ace Di2 ST-R9250
  • 後變速器
    Shimano Dura-Ace Di2 ST-R9250
  • 煞車系統
    Shimano Dura-Ace Di2 hydraulic, Shimano RT-MT900 rotors [F]160mm, [R]140mm
  • 煞車把手
    Shimano Dura-Ace Di2
  • 飛輪
    Shimano Dura-Ace, 12-speed, 11x34
  • 鍊條
    Shimano Dura-Ace M9100
  • 大齒盤
    Shimano Dura-Ace, 36/52 with Shimano FC-9200P power meter XXS:165mm, XS:165mm, S:170mm, M:170mm, L:172.5mm
  • Bottom Bracket (B B)
    Shimano, press fit
  • 輪圈
    CADEX 36 Disc WheelSystem, [F] 36mm, [R] 36mm
  • 花鼓
    [F] CADEX Low Friction Hub, CenterLock, 12mm thru-axle, [R] CADEX R1-C30 Hub, CenterLock, 12mm thru-axle
  • 輻條
    CADEX Aero Carbon
  • 外胎
    CADEX Race, tubeless, 700x25c (28mm), folding
  • 其他
    computer mount, tubeless prepared, 32mm max tire size
  • 重量
    最準確的重量請依全省捷安特通路實際量測為主,市面上多數品牌商所提供的重量皆為"可能"的最低重量,但實際車重會依車架尺寸、零配件等有所不同,而我們致力於提供您同級最佳的重量及騎乘品質。

*捷安特公司對本網站所刊載之產品資料保留修改權利,恕不另行通知(包括有關設備、規格、型號、重量、顏色和材料等),請以實際產品為主。
