Vall E+ 3

What is my size?

Deli

EVERY RIDE JUST GOT MORE EPIC.

Glavne značilnosti

Accessible and Reliable

Access to new trails and experiences is easily within reach thanks to the up to 170 km* range of the ultra-reliable EnergyPak Smart 500Wh battery. The SyncDrive Sport motor, powered by Yamaha, delivers 70Nm of torque and has six speed control settings, with a maximum 350% support. *Actual range depends on several factors including weight, elevation, terrain and acceleration.

Integrated Design

Along with the integrated speed sensor, the EnergyPak Smart battery is integrated into the downtube and easily accessible.

Smooth Riding

Smart Assist Technology smooths out bumps, and the handlebar-mounted RideControl Dash is makes it easy to select pedal assist functions and view battery levels.

Tehnologije

ALUXX Aluminum Technology
EnergyPak - Side Release
SyncDrive Sport
Smart Assist
RideControl Dash

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XS
      152 cm5’0”  to 163 cm5’4”
  • S
      158 cm5’2”  to 169 cm5’7”
  • M
      164 cm5’5”  to 175 cm5’9”
  • L
      170 cm5’7”  to 181 cm5’11”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  XSSML
ADolžina sedežne cevi (mm) (inch)36514,440515,944517,548519,1
BKot sedežne cevi (degrees)74,0°73,5°73,0°73,0°
CTop Tube Length (mm) (inch)5602256522,259523,461524,2
DVišina glave okvirja (mm) (inch)1104,31154,51054,11154,5
EKrmilni kot (degrees)68,0°68,0°68,0°68,0°
FZamik vpetja osi (mm) (inch)421,7421,7461,8461,8
GTrail (mm) (inch)103,84,1103,84,199,53,999,53,9
HMedosna razdalja (mm) (inch)113044,5113044,5116145,7118246,5
IDolžina cevi ob verigi (mm) (inch)47518,747518,747518,747518,7
JBottom Bracket Drop (mm) (inch)502502451,8451,8
KOddaljenost zgornje cevi od gonilne osi (mm) (inch)62124,462624,662524,663425
LDoseg (mm) (inch)382153801540415,942116,6
MVišina zgornje cevi (mm) (inch)68026,87102875029,575529,7
NŠirina krmila (mm) (inch)69027,269027,275029,575029,5
ODolžina opore krmila (mm) (inch)401,6502502602,4
PDolžina gonilke (mm) (inch)1656,51656,51706,71706,7
QVelikost obročnikov [F] 27.5+"[F] 27.5+"[F] 29" [R[F] 29" [R
Specifikacije
  • Motor
    Giant SyncDrive Sport, 70Nm, powered by Yamaha, PedalPlus 6-sensor technology
  • Tipalo
    Giant RideControl Dash, Smart Assist automatic mode, 5 support levels, USB-C (10W)
  • Prikazovalnik
    Giant RideControl Dash, high-angle visibility, full color LCD display
  • Baterija
    Giant EnergyPak 500Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 250 range extender compatible
  • Velikosti
    S, M, L, XL
  • Barve
    1 Colors
  • Okvir
    ALUXX aluminum, Overdrive 1½ - 1⅛" head tube, 141mm Boost QR, ISS, EnergyPak Plus Range Extender compatible, integrated KSA18 kickstand mount
  • Vilice
    SR Suntour XCM32 NLO DS 15AH2, 27.5 [XS-S] / 29 [M-L], 120mm travel, tapered steerer, lockout
  • Amortizer
    n/a
  • Krmilo
    Connect TR Riser 31.8x690mm [XS-S], 750mm [M-L]
  • Grips
    Tactal single lock-on
  • Opora krmila
    Contact 31.8 alloy
  • Opora sedeža
    Forge alluminum 30.9mm 2-bolt micro adjustable
  • Sedež
    Liv Sport
  • Pedala
    Aluminum Platform
  • Prestavne ročice
    microSHIFT ADVENT e-optimized
  • Prednji menjalnik
    n/a
  • Zadnji menjalnik
    microSHIFT ADVENT, 9-speed
  • Zavore
    Tektro HD-M285, hydraulic disc, 180mm
  • Zavorne ročice
    Tektro HD-M285
  • Verižnik
    microSHIFT ADVENT, 11-42T, 9-speed, e-optimized
  • Veriga
    KMC e.9 Sport, e-bike optimized
  • Gonilke z verižniki
    FSA MegaTooth direct-mount 1X steel 36T alloy crank arm
  • Bottom Bracket
    n/a
  • Obroči
    XCT 27.5 [XS-S] / 29 [M-L] Tubeless Ready 25mm e-bike optimized
  • Pesta
    Shimano MT400 Boost, Center-Lock, 110x15 [XS-S] / Shimano HB-TC500-15 100x15 [M-L] [F], MT200-B 141mm OLD, QR [R]
  • Napere
    Stainless steel
  • Plašči
    Maxxis Rekon 27.5x2.4" [XS-S] / 29x2.4" [M-L], Wire Bead 60TPI
  • Dodatki
    -
  • Svetila
    -
  • Ključavnica
    -
  • Prtljažnik
    -
  • Teža
    Koliko tehta to kolo? To je pogosto vprašanje. A v resnici v kolesarstvu ni standardov za uradne teže koles, zato je veliko zavajajočih podatkov. Do razlik prihaja zaradi velikosti, materialov okvirja, končne obdelave in opreme. Pri vse lažjih kolesih so te razlike kritične. Pri Giantu verjamemo, da je edini pravi podatek o teži tisti, do katerega boste prišli sami pri vašem prodajalcu.

Vse navedene specifikacije se lahko spremenijo brez obvestila.

Vse navedene specifikacije se lahko spremenijo brez obvestila.

}
