Vall-E+ 1 Pro

2018

Deli

EPIC RIDES ARE NOW WITHIN REACH. ACCESS THE MOUNTAINOUS ADVENTURES OF YOUR DREAMS.

Why We Love It
Whether you’re looking to ride faster, go farther or get your fitness back, Vall-E+ will take you beyond boundaries. Reach those mountain peaks and descend to the valleys below. Vall-E+ Pro is your backstage pass for access to bigger rides, faster paces and living your wildest adventures. With Vall-E+ Pro it is easier to push at your fitness and reach the peaks with your fastest buddy with the natural feeling battery-assisted pedaling. Explore further and rediscover a passion as you pedal to the tops of longer climbs and gain the thrill of longer descents.

  • Giant SyncDrive Pro motor with 80Nm torque, powered by Yamaha, with five levels of assistance for speed control, ranging from 100% to 360%
  • 100mm/120mm suspension fork to smooth out bumps and bobbles
  • New side-pull battery and case for easy removal and insertion of battery for charging, replacing and storing
  • 2.6” Tubeless Plus tires to increase comfort and stability
  • Low standover height for ease in getting on and off, even on steeper terrain
  • Handlebar mounted control lets you adjust riding modes
  • Mobile app that allows you to see your ride information and upgrade the system
  • Lightweight and highly durable in-house manufactured ALUXX-SL frame
  • Hybrid Cycling Technology
  • Designed using Liv’s 3F Design Philosophy to build bikes for women
  • 27.5-in wheel size optimizes traction and efficiency
  • LivRight Sizing Philosophy for the perfect fit across all sizes
  • SyncDrive Pro Motor
  • Giant PedalPlus 4-sensor Technology for smooth ride across varying terrain
  • EnergyPak 500 for longest range
  • RideControl Evo
  • Giant SyncDrive Pro central motor, powered by YAMAHA
  • Giant EnergyPak500 lithium-ion battery for longest range
  • SR Suntour Raidon 34 LO-R Air 120mm-travel fork
  • Shimano Deore/XT 10-speed drivetrain
  • Shimano M506 hydraulic disc brakes
  • Color: White/Mint

Prenesite PDF

VelikostiXS,S, M, L
BarveWhite/Mint
OkvirALUXX SL-Grade Aluminum
ViliceSR Suntour Raidon 34 LO-R Air 120mm travel, Tapered 1½ - 1⅛" steerer,15QR, lockout
KrmiloGiant Connect Trail 730x31,8mm
Opora krmilaGiant Connect
Opora sedežaGiant Connect
SedežLiv Contact Upright
PedalaAluminum Platform
Prestavne ročiceShimano new Deore M6000 10sp i-spec II
Zadnji menjalnikShimano Deore XT shadow+, 10sp
ZavoreShimano BR-MT500 180/200mm Disc
Zavorne ročiceShimano BL-MT500 i-spec II
VerižnikShimano HG-M6000 11-42 T, 10-sp
VerigaKMC X.10e, e-bike optimized
Gonilke z verižnikiCustom forged crankset, Samox AONE 38T, Boost 1x spider
ObročiGiant GE35, Tubeless ready, 27.5" 35mm aluminum, e-bike optimized
PestaGiant eTracker Boost, Sealed Cartridge bearing, IS 6-bolt, [F] 110x15 [R] 148x12mm Thru-axle, e-bike optimized
NapereGiant eTracker Boost, Sealed Cartridge bearing, IS 6-bolt, [F] 110x15 [R] 148x12mm Thru-axle, e-bike optimized
PlaščiMaxxis Forekaster 27.5x2.6, foldable, Exo protect, Tubeless
DodatkiGiant EnergyPak 3A fast charger
MotorGiant SyncDrive Pro
TipalaGiant PedalPlus 4-sensor technology
PrikazovalnikGiant RideControl EVO, grip launch control with walk assist, mini USB charger
BaterijaGiant EnergyPak 500, 36V 11.3Ah Rechargeable Lithium-Ion
TežaKoliko tehta to kolo? To je pogosto vprašanje. A v resnici v kolesarstvu ni standardov za uradne teže koles, zato je veliko zavajajočih podatkov. Do razlik prihaja zaradi velikosti, materialov okvirja, končne obdelave in opreme. Pri vse lažjih kolesih so te razlike kritične. Pri Giantu verjamemo, da je edini pravi podatek o teži tisti, do katerega boste prišli sami pri vašem prodajalcu.

Poudarki

Whether you’re looking to ride faster, go farther or get your fitness back, Vall-E+ Pro will take you beyond boundaries. Reach those mountain peaks and descend to the valleys below. Vall-E+ Pro is your backstage pass for access to bigger rides, faster paces and living your wildest adventures. With Vall-E+ Pro it is easier to push at your fitness and reach the peaks with your fastest buddy with the natural feeling battery-assisted pedaling. Explore further and rediscover a passion as you pedal to the tops of longer climbs and gain the thrill of longer descents.

1 2 3 4 5 6 7 8 9

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.

  XSSML
ADolžina sedežne cevi (mm) (inch)36514,440515,946018,151020,1
BKot sedežne cevi (degrees)74,0°73,5°73,0°73,0°
CTop Tube Length (mm) (inch)55021,756522,25852360023,6
DVišina glave okvirja (mm) (inch)1104,31154,51355,31505,9
EKrmilni kot (degrees)68,0°68,0°68,0°68,0°
FZamik vpetja osi (mm) (inch)421,7421,7421,7421,7
GTrail (mm) (inch)1003,91003,91003,91003,9
HMedosna razdalja (mm) (inch)111643,9112644,3114245115845,6
IDolžina cevi ob verigi (mm) (inch)47518,747518,747518,747518,7
JBottom Bracket Drop (mm) (inch)502502502502
KOddaljenost zgornje cevi od gonilne osi (mm) (inch)61224,161724,36352564925,6
LDoseg (mm) (inch)37414,73821539015,440115,8
MVišina zgornje cevi (mm) (inch)67426,569627,474229,276330
NŠirina krmila (mm) (inch)69027,269027,275029,575029,5
ODolžina opore krmila (mm) (inch)502502602,4702,8
PDolžina gonilke (mm) (inch)1706,71706,71706,71706,7
QVelikost obročnikov 27.5+27.5+27.5+27.5+

Vse navedene specifikacije se lahko spremenijo brez obvestila.
