Pique Advanced
Pro 29 1

Key Performance Factors

Fast

A light and stiff Advanced-Grade Composite frame and wheelset maximizes your power and efficiency, especially noticeable on climbs.

Capable

29-inch wheels easily roll over small obstacles, while 100mm of Maestro suspension – tuned for women, by women – help absorb rougher trails.

Stable

An integrated dropper seatpost and clearance for up to 2.4-inch tires means you can confidently ride moderately technical terrain.

Highlights

Pique Advanced Pro 29 with interactive tooltips

Techs & Features

Ghid de marimi si Geometrii

Marimile prezentate mai jos sunt numai de referinta. Pentru alegerea unei marimi corecte este necesar sa vizitati un Dealer Giant sau Liv, sau sa cereti consultanta online.

XS
148 cm4’10” 163 cm5’4”
S
158 cm5’2” 169 cm5’7”
M
164 cm5’5” 175 cm5’9”
L
170 cm5’7” 183 cm6’0”

bike diagram with measurements referenced in table that follows

		XS	S	M	L
A	Seat Tube Length (mm) (inch)	39015,4	40616	44517,5	48219
B	Seat Tube Angle (degrees)	74,0°	74,0°	74,0°	74,0°
C	Top Tube Length (mm) (inch)	56522,2	58022,8	59523,4	61024
D	Head Tube Length (mm) (inch)	903,5	953,7	1003,9	1104,3
E	Head Tube Angle (degrees)	68,5°	68,5°	68,5°	68,5°
F	Fork Rake (mm) (inch)	512	512	512	512
G	Trail (mm) (inch)	92,93,6	92,93,6	92,93,6	92,93,6
H	Wheelbase (mm) (inch)	110043,3	111543,9	113144,5	114745,2
I	Chain Stay Length (mm) (inch)	43817,2	43817,2	43817,2	43817,2
J	Bottom Bracket Drop (mm) (inch)	451,8	451,8	451,8	451,8
K	Stack (mm) (inch)	57822,8	58323	58723,1	59723,5
L	Reach (mm) (inch)	39915,7	41316,3	42716,8	43917,3
M	Stand Over Height (mm) (inch)	69327,3	70327,7	72628,6	75329,6
N	Handlebar Width (mm) (inch)	72028,3	72028,3	74029,1	74029,1
O	Stem Length (mm) (inch)	502	502	602,4	702,8
P	Crank Length (mm) (inch)	1656,5	1706,7	1706,7	1756,9
Q	Wheel Size	29"	29"	29"	29"

Marimi
XS, S, M, L
Culori
Dark Blue / Carbon
Cadru
Advanced-Grade Composite front and rear triangles, 100mm Maestro Suspension
Furca
Fox 32 Float SC Performance Elite Live Valve, 100mm, FIT4 damper, Boost 15x110 Kabolt, tapered, 44mm offset, custom tuned for Liv
Soc
Fox Float Performance Elite Live Valve, 165/45, custom tuned for Liv
Ghidon
Giant Contact SLR XC, flat, 760x35mm
Grips
Liv Supera, single lock ring
Pipa
Giant Contact SL XC, 35mm XS:50mm, S:50mm, M:60mm, L:70mm
Tija sa
Giant Contact Switch dropper, remote XS: 75mm travel / 30.9 x 295mm S: 100mm travel / 30.9 x 345mm M: 100mm travel / 30.9 x 345mm L: 100mm travel / 30.9 x 345mm
Sa
Fi'zi:k Vento Argo R5
Pedale
platform
Manete schimbator
Shimano Deore XT M8100, 1x12
Schimbator fata
N/A
Schimbator spate
Shimano Deore XT M8100
Frane
Shimano SLX M7100, hydraulic, Shimano RT-64 rotors [F]180mm, [R]160mm
Manete frana
Shimano SLX M7100
Pinioane
Shimano SLX M7100, 10x51
Lant
KMC X-12
Angrenaj
Shimano Deore XT M8100, 30t XS:165mm, S:170mm, M:170mm, L:175mm
Bottom Bracket
Shimano, press fit
Jante
Giant XCR-1 Carbon 29 WheelSystem
Butuci
Giant XCR-1 Carbon 29 WheelSystem
Spite
Giant XCR-1 Carbon 29 WheelSystem
Anvelope
[F] Maxxis Recon Race, 29x2.25", foldable, TLR, EXO, tubeless [R] Maxxis Recon Race, 29x2.25", foldable, TLR, EXO, tubeless
Extras
tubeless prepared, max tire size 2.25", max chainring size 32t
Greutate
Cat cantareste bicicleta? Este o intrebare uzuala si indreptatita. Adevarul este ca nu exista un standard al industriei care sa reglementeze aceasta masurare, si asta duce la multe confuzii. Variatiile au drept cauza marimile si materialul cadrului, finisajele si echiparile. Cum tendinta este spre o greutate mai redusa, fiecare astfel de detaliu conteaza. GIANT considera ca singura cale prin care poti fi sigur 100% de greutatea unei biciclete este de a solicita cantarirea ei la magazin.
