This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
| S | M | L | ||
|---|---|---|---|---|
| Seat Tube Length (mm) (inch) | 45017,7 | 50019,7 | 55021,7 | |
| Seat Tube Angle (degrees) | 73,0° | 73,0° | 73,0° | |
| Top Tube Length (mm) (inch) | 57022,4 | 58022,8 | 59023,2 | |
| Head Tube Length (mm) (inch) | 1606,3 | 1756,9 | 1907,5 | |
| Head Tube Angle (degrees) | 69,0° | 69,0° | 69,0° | |
| Fork Rake (mm) (inch) | 421,7 | 421,7 | 421,7 | |
| Trail (mm) (inch) | 953,7 | 953,7 | 953,7 | |
| Wheelbase (mm) (inch) | 108842,8 | 109943,3 | 111043,7 | |
| Chain Stay Length (mm) (inch) | 45517,9 | 45517,9 | 45517,9 | |
| Bottom Bracket Drop (mm) (inch) | 702,8 | 702,8 | 702,8 | |
| Stack (mm) (inch) | 64325,3 | 65725,9 | 67126,4 | |
| Reach (mm) (inch) | 37314,7 | 37914,9 | 38515,2 | |
| Stand Over Height (mm) (inch) | 47418,7 | 46918,5 | 45918,1 | |
| Handlebar Width (mm) (inch) | 62024,4 | 62024,4 | 62024,4 | |
| Stem Length (mm) (inch) | 903,5 | 903,5 | 1104,3 | |
| Crank Length (mm) (inch) | 1756,9 | 1756,9 | 1756,9 | |
| Wheel Size | 700C | 700C | 700C |
This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
Toate specificatiile enumerate se pot schimba fara notificare prealabila.
