All-new internal cable routing hides derailleur and brake housing from the wind for maximum aerodynamic advantage and improved aesthetics
This is an image carousel with thumbnail navigation. Select any thumbnail to view an enlarged version in a gallery modal. In the gallery, use the Next and Previous buttons to navigate between images, or close the modal to return to the thumbnails.
Avow Advanced Pro 1
Perfect fit, ease of adjustment and aerodynamics create an unstoppable trifecta in the world’s first truly women’s performance triathlon bike.
Key Performance Factors
Absolutely Aerodynamic
From the aero frame design to the wheels, fork, and base bar, Avow vanquishes wind resistance for top speed and performance.
Built for Endurance
An array of body-positioning options conserve energy in key muscle groups for the run. Plus, frame-integrated hydration and storage help keep you fueled.
Powerful
Proprietary oversized bottom-bracket and symmetric chainstay design increase stiffness to maximize power transfer.
Highlights
1
Internal Cable Routing
2
Advanced-Grade Composite Frame
A lightweight Advanced-Grade Composite frame is hand-crafted in-house to provide optimally tuned stiffness and compliance
3
AeroSystem Shaping Technology
Data compiled from Computational Fluid Dynamics research and wind-tunnel tests was used to optimize the shape of every frameset tube and junction for overall system aerodynamics
4
Vector Seatpost
This full-composite, lightweight and highly aerodynamic seatpost is engineered specifically for the unyielding demands of the performance triathlete
5
SpeedControl Brake System
This proprietary braking system offers powerful, aerodynamic stopping power. A composite reverse-position front brake and seatstay-mounted rear brake are hidden from the wind. The system also features strategic trailing edges that further improve aerodynamics
6
AeroVault System
The AeroVault System keeps all the essentials in reach by integrating hydration and storage into the bike
7
AeroDrive Tri Composite Base Bar
Triathlon-specific 5:1 airfoil base bar delivers the ultimate aerodynamic performance and features a reversible design, giving riders 40-millimeters of height adjustment
Techs & Features
Advanced Composite Technology
Liv’s High-Performance Grade raw carbon material is used to produce this frameset in our own composite factory. Using state-of-the-art materials and manufacturing techniques, Liv’s Advanced-Grade Composite frames are designed to offer light weight and stiffness with optimal compliance.
AeroSystem Shaping Technology
Tubing shapes engineered using computational fluid dynamics (CFD) and wind-tunnel data to optimize each tube shape for superior aerodynamic performance.
OverDrive
Designed to provide precise front-end steering performance, this fork steerer tube technology uses oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
PowerCore
A massively oversized bottom-bracket/chainstay area features a fully integrated, 86-millimeter wide bottom-bracket design (92-millimeterwide for off-road bikes). Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.
Tubeless System
Engineered with proprietary Dynamic Balanced Lacing technology, this tubeless ready composite WheelSystem delivers superior efficiency, pinpoint control and comfort.
Sizing Guide and Geometry
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
- XXS
- 151 cm4’11”
161 cm5’3”
- XS
- 159 cm5’3” 169 cm5’7”
- S
- 166 cm5’5” 176 cm5’9”
- M
- 173 cm5’8” 182 cm6’0”
| XXS | XS | S | M | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 45017,7 | 48018,9 | 51020,1 | 53020,9 |
| B | Seat Tube Angle (degrees) | 77,0° | 77,0° | 77,0° | 77,0° |
| C | Top Tube Length (mm) (inch) | 48018,9 | 50019,7 | 51520,3 | 54021,3 |
| D | Head Tube Length (mm) (inch) | 803,1 | 803,1 | 953,7 | 1254,9 |
| E | Head Tube Angle (degrees) | 71,5° | 72,0° | 72,5° | 72,5° |
| F | Fork Rake (mm) (inch) | 401,6 | 401,6 | 401,6 | 401,6 |
| G | Trail (mm) (inch) | 622,4 | 682,7 | 642,5 | 642,5 |
| H | Wheelbase (mm) (inch) | 94937,4 | 96137,8 | 97438,3 | 100139,4 |
| I | Chain Stay Length (mm) (inch) | 40515,9 | 40515,9 | 40515,9 | 40515,9 |
| J | Bottom Bracket Drop (mm) (inch) | 642,5 | 753 | 753 | 753 |
| K | Stack (mm) (inch) | 44217,4 | 49019,3 | 50419,8 | 53421 |
| L | Reach (mm) (inch) | 37814,9 | 38715,2 | 39815,7 | 41716,4 |
| M | Stand Over Height (mm) (inch) | 70827,9 | 74029,1 | 76730,2 | 78831 |
| N | Handlebar Width (mm) (inch) | 40015,7 | 40015,7 | 40015,7 | 40015,7 |
| O | Stem Length (mm) (inch) | 803,1 | 803,1 | 803,1 | 803,1 |
| P | Crank Length (mm) (inch) | 1606,3 | 1656,5 | 1656,5 | 1656,5 |
| Q | Wheel Size | 700C | 700C | 700C | 700C |
