Formed from raw materials in Liv’s own forging facility, this proprietary alloy features 30 percent additional stiffness over traditional 6061-series aluminum, while also reducing overall weight
{{ productAwardLocalized.Quote }}
EVERY RIDE JUST GOT MORE EPIC.
Key Performance Factors
Accessible and Reliable
Access to new trails and experiences is easily within reach thanks to the up to 170 km* range of the ultra-reliable EnergyPak Smart 500Wh battery. The SyncDrive Sport motor, powered by Yamaha, delivers 70Nm of torque and has six speed control settings, with a maximum 350% support. *Actual range depends on several factors including weight, elevation, terrain and acceleration.
Integrated Design
Along with the integrated speed sensor, the EnergyPak Smart battery is integrated into the downtube and easily accessible.
Smooth Riding
Smart Assist Technology smooths out bumps, and the handlebar-mounted RideControl Dash is makes it easy to select pedal assist functions and view battery levels.
Range
How far can I expect to ride on a single battery charge?
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
EnergyPak Smart 500 / SyncDrive Sport
Highlights
Sizing Guide and Geometry
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
- XS
- 152 cm5’0”
163 cm5’4”
- S
- 158 cm5’2” 169 cm5’7”
- M
- 164 cm5’5” 175 cm5’9”
- L
- 170 cm5’7” 181 cm5’11”
| XS | S | M | L | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 36514.4 | 40515.9 | 44517.5 | 48519.1 |
| B | Seat Tube Angle (degrees) | 74.0° | 73.5° | 73.0° | 73.0° |
| C | Top Tube Length (mm) (inch) | 56022 | 56522.2 | 59523.4 | 61524.2 |
| D | Head Tube Length (mm) (inch) | 1104.3 | 1154.5 | 1054.1 | 1154.5 |
| E | Head Tube Angle (degrees) | 68.0° | 68.0° | 68.0° | 68.0° |
| F | Fork Rake (mm) (inch) | 421.7 | 421.7 | 461.8 | 461.8 |
| G | Trail (mm) (inch) | 103.84.1 | 103.84.1 | 99.53.9 | 99.53.9 |
| H | Wheelbase (mm) (inch) | 113044.5 | 113044.5 | 116145.7 | 118246.5 |
| I | Chain Stay Length (mm) (inch) | 47518.7 | 47518.7 | 47518.7 | 47518.7 |
| J | Bottom Bracket Drop (mm) (inch) | 502 | 502 | 451.8 | 451.8 |
| K | Stack (mm) (inch) | 62124.4 | 62624.6 | 62524.6 | 63425 |
| L | Reach (mm) (inch) | 38215 | 38015 | 40415.9 | 42116.6 |
| M | Stand Over Height (mm) (inch) | 68026.8 | 71028 | 75029.5 | 75529.7 |
| N | Handlebar Width (mm) (inch) | 69027.2 | 69027.2 | 75029.5 | 75029.5 |
| O | Stem Length (mm) (inch) | 401.6 | 502 | 502 | 602.4 |
| P | Crank Length (mm) (inch) | 1656.5 | 1656.5 | 1706.7 | 1706.7 |
| Q | Wheel Size | 27.5+ | 27.5+ | 29" | 29" |
Techs & Features
ALUXX Aluminum Technology
This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
Hybrid Cycling Technology
Hybrid Cycling Technology is a system that combines electric power with human power to produce the most efficient, powerful and natural E-bike riding experience. It’s a seamless extension of a rider’s own power that sets Liv and Giant E-bikes apart from other “electric” bicycles. The system consists of four key innovative technologies that work in unison with your own body’s power output—a seamless extension of your own capabilities.
EnergyPak
EnergyPak side release design makes it easy to handle and remove the battery from the E-bike, plus the battery can be charged on or off the bike for convenience.
SyncDrive Sport
Innovation, manufacturing expertise and a motor system powered by Yamaha all combine to expand any rider’s abilities. SyncDrive Sport offers three support modes and is equipped on E-bikes that are used for both everyday riding and for more demanding off-road riding. This small mid-drive motor delivers a massive maximum 80Nm of torque and is widely acclaimed for its performance and reliability.
Smart Assist
With Smart Assist you can enjoy seamless acceleration and power boost. The Smart Assist Technology system replicates a natural riding style, using the six sensors to add assistance exactly when needed.
