The Thrive is a fast, fun and confident fitness bike ready for short daily spins or long road rides.

Key Performance Factors

Comfort

An upright riding position, flat handlebars and D-Fuse seatpost make commuting or a casual spin comfortable without compromising efficiency.

Fun Fitness

The lightweight, balanced geometry of the ALUXX-Grade Aluminum frame provides an energizing combination of speed and stability.

Control

Pedaling efficiency, reliable shifting and powerful braking are a perfect trio for predictable cruising.

Highlights

Thrive-2022 with interactive tooltips

Techs & Features

ALUXX Aluminum Technology
Compact Road Design
D-Fuse Seatpost

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XS
      148 cm4’10”  to 163 cm5’4”
  • S
      158 cm5’2”  to 169 cm5’7”
  • M
      164 cm5’5”  to 175 cm5’9”
  • L
      170 cm5’7”  to 183 cm6’0”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  XSSML
ASeat Tube Length (mm) (inch)37014.642016.546518.350019.7
BSeat Tube Angle (degrees)74.0°74.0°74.0°74.0°
CTop Tube Length (mm) (inch)52520.754021.35602258022.8
DHead Tube Length (mm) (inch)1054.11254.91505.91756.9
EHead Tube Angle (degrees)70.5°71.0°71.0°71.0°
FFork Rake (mm) (inch)502502502502
GTrail (mm) (inch)70.82.867.82.6682.7682.7
HWheelbase (mm) (inch)101740103440.7105041.3107242.2
IChain Stay Length (mm) (inch)43016.943016.943016.943016.9
JBottom Bracket Drop (mm) (inch)602.4602.4602.4602.4
KStack (mm) (inch)51420.253521.15582258222.9
LReach (mm) (inch)37714.839215.440015.741316.3
MStand Over Height (mm) (inch)66726.370627.874329.377330.4
NHandlebar Width (mm) (inch)60023.660023.664025.264025.2
OStem Length (mm) (inch)803.1803.1903.51003.9
PCrank Length (mm) (inch)1656.51706.71706.7172.56.8
QWheel Size 700C700C700C700C
Specs
  • Sizes
    XS, S, M, L
  • Colors
    Metal
  • Frame
    ALUXX-Grade Aluminum
  • Fork
    composite, alloy steerer, disc
  • Shock
    N/A
  • Handlebar
    Giant Connect, flat XS:58cm, S:58cm, M:62cm, L:62cm
  • Grips
    Giant Connect Ergo
  • Stem
    Giant Contact, 8-degree XS:80mm, S:80mm, M:90mm, L:100mm
  • Seatpost
    Giant D-Fuse, alloy, 350mm
  • Saddle
    Liv Sport
  • Pedals
    platform pedal
  • Shifters
    Shimano Claris, 2x8
  • Front Derailleur
    Shimano Claris
  • Rear Derailleur
    Shimano Claris
  • Brakes
    Tektro HD-R280, hydraulic [F]160mm, [R]140mm
  • Brake Levers
    Tektro hydraulic
  • Cassette
    Shimano CS-HG41, 11x34
  • Chain
    KMC X8.3
  • Crankset
    ProWheel Ounce 521C, 34/50 XS:165mm, S:170mm, M:170mm, L:172.5mm
  • Bottom Bracket
    cartridge
  • Rims
    Giant GX Disc wheelset
  • Hubs
    Giant GX Disc wheelset
  • Spokes
    Giant GX Disc wheelset
  • Tires
    Giant S-R3 AC, 700x32c
  • Extras
    35mm max tire size
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
