Best For: Trail
Lurra 2
This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
This is an image carousel with thumbnail navigation. Select any thumbnail to view an enlarged version in a gallery modal. In the gallery, use the Next and Previous buttons to navigate between images, or close the modal to return to the thumbnails.
Lurra 1
Similar Products
Feel more connected to the trail with the all-new Lurra. Built for charging up singletrack climbs and diving into fast, flowy descents, this hardtail trail bike is simplicity at its best.
Ključni faktori
Optimal Trail Design
Lightweight ALUXX SL-grade aluminum hardtail frame with a steep seat tube angle optimizes your input when powering up climbs and hammering on the flats, resulting in greater efficiency and speed. And a 66-degree head tube angle offers confidence on steep
Boosted Confidence
Take on technical terrain with the 130mm of plush front suspension, high-volume tubeless tires offering extreme traction on roots, rocks and ruts, and a dropper seatpost allowing you to get low and ride with control.
Adventure-Ready
Equipped with mounts for 2 water bottle cages and a small gear bag on the underside of the top tube for extra tools and snacks. Internal cable routing keeps the important stuff tidy and protected, so you can stay focused on the ride ahead.
Tehnologije
ALUXX Aluminum Technology
OverDrive
Designed to provide precise front-end steering performance, this fork steerer tube technology uses oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
PowerCore
A massively oversized bottom-bracket/chainstay area features a fully integrated, 86-millimeter wide bottom-bracket design (92-millimeterwide for off-road bikes). Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.
Tubeless System
Engineered with proprietary Dynamic Balanced Lacing technology, this tubeless ready composite WheelSystem delivers superior efficiency, pinpoint control and comfort.
Vodič za određivanje veličine i geometrija
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
- XS (27.5")
- 150 cm4’11”
163 cm5’4”
- S (27.5")
- 158 cm5’2” 169 cm5’7”
- S (29")
- 158 cm5’2” 169 cm5’7”
- M (29")
- 164 cm5’5” 175 cm5’9”
- L (29")
- 170 cm5’7” 181 cm5’11”
| XS (27.5") | S (27.5") | S (29") | M (29") | L (29") | ||
|---|---|---|---|---|---|---|
| A | Dužina cijevi sjedala (mm) (inch) | 36014,2 | 38015 | 38015 | 41016,1 | 43016,9 |
| A1 | Seat Post Insertion Depth (mm) (inch) | 29011,4 | 29011,4 | 29011,4 | 34013,4 | 36014,2 |
| B | Kut cijevi sjedala (degrees) | 76,0° | 76,0° | 76,5° | 76,5° | 76,5° |
| C | Dužina gornje cijevi (mm) (inch) | 54421,4 | 56422,2 | 55421,8 | 57522,6 | 59623,5 |
| D | Dužina prednje cijevi (mm) (inch) | 953,7 | 1054,1 | 903,5 | 1003,9 | 1104,3 |
| E | Kut vilice (degrees) | 66,0° | 66,0° | 66,0° | 66,0° | 66,0° |
| F | Zakrivljenost vilice (offset) (mm) (inch) | 441,7 | 441,7 | 441,7 | 441,7 | 441,7 |
| G | Staza (mm) (inch) | 113,94,4 | 113,94,4 | 121,74,8 | 121,74,8 | 121,74,8 |
| H | Međuosovinski razmak kotača (mm) (inch) | 111844 | 114044,9 | 113644,7 | 115945,6 | 118246,5 |
| I | Dužina od osovine pogona do osovine zadnjeg kotača (CS) (mm) (inch) | 43817,2 | 43817,2 | 43817,2 | 43817,2 | 43817,2 |
| J | Položaj osovine pogona (mm) (inch) | 602,4 | 602,4 | 602,4 | 602,4 | 602,4 |
| K | Vertikalna dužina od osovine pogona do glave okvira (stack) (mm) (inch) | 60823,9 | 61724,3 | 61824,3 | 62724,7 | 63625 |
| L | Horizontalna dužina od osovine pogona do glave okvira (reach) (mm) (inch) | 39315,5 | 41016,1 | 40616 | 42516,7 | 44317,4 |
| M | Prekoračna visina (mm) (inch) | 61324,1 | 66126 | 66126 | 71228 | 73729 |
| N | Širina volana (mm) (inch) | 76029,9 | 76029,9 | 76029,9 | 76029,9 | 78030,7 |
| O | Dužina lule volana (mm) (inch) | 401,6 | 401,6 | 401,6 | 502 | 502 |
| P | Dužina poluge pedale (mm) (inch) | 1656,5 | 1706,7 | 1706,7 | 1706,7 | 1706,7 |
| Q | Veličina kotača | 27.5" | 27.5" | 29" | 29" | 29" |
Sve navedene specifikacije podložne su promjeni bez prethodne najave.
