Langma's frame geometry is designed from the ground up to help women achieve the highest level of performance, while no-compromise components and women's-specific contact points ensure comfort where women need it most
THIS FEATHER-LIGHT RACING BIKE DELIVERS THE SPEED AND STRENGTH NEEDED FOR ANY CLIMB, RACE OR RIDE.
Ključni faktori
Lightweight
Langma SL frame is built from high-performing and durable ALUXX-SL aluminum, and will prove itself as a precise climbing weapon.
Aero-features
Innovative tubing slices through the wind without sacrificing weight or stiffness.
Precise Handling
This climbing weapon can tackle the descents or any technical flat corner, with appropriate lateral stiffness and control.
Zašto to volimo
The Langma SL is engineered with our lightweight ALUXX-SL frame material to conquer the steepest climbs, power through flats, and rail technical descents. The downtube tapers to a thicker square-shape at the PowerCore bottom bracket, which creates an extremely lightweight and fast racing machine, without compromising strength or pedaling stiffness. With Liv’s 3F Design Philosophy and cutting-edge aerodynamic innovations on a compact frame design, this nimble and strong bike provides the winning advantage on every effort, from mountainous road races to aggressive criteriums.
Istaknuto
Vodič za određivanje veličine i geometrija
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
- XXS
- 145 cm4’9”
157 cm5’2”
- XS
- 152 cm5’0” 163 cm5’4”
- S
- 158 cm5’2” 169 cm5’7”
- M
- 164 cm5’5” 176 cm5’9”
- L
- 170 cm5’7” 183 cm6’0”
| XXS | XS | S | M | L | ||
|---|---|---|---|---|---|---|
| A | Dužina cijevi sjedala (mm) (inch) | 38515,2 | 41016,1 | 44517,5 | 48018,9 | 51520,3 |
| B | Kut cijevi sjedala (degrees) | 75,0° | 75,0° | 74,5° | 74,0° | 73,5° |
| C | Dužina gornje cijevi (mm) (inch) | 49719,6 | 50720 | 52420,6 | 54021,3 | 55521,9 |
| D | Dužina prednje cijevi (mm) (inch) | 1104,3 | 1154,5 | 1305,1 | 1505,9 | 1706,7 |
| E | Kut vilice (degrees) | 70,5° | 71,0° | 72,0° | 72,5° | 72,5° |
| F | Zakrivljenost vilice (offset) (mm) (inch) | 491,9 | 491,9 | 451,8 | 451,8 | 451,8 |
| G | Staza (mm) (inch) | 68,82,7 | 65,62,6 | 63,52,5 | 60,32,4 | 60,32,4 |
| H | Međuosovinski razmak kotača (mm) (inch) | 96638 | 97238,3 | 97438,3 | 98138,6 | 99139 |
| I | Dužina od osovine pogona do osovine zadnjeg kotača (CS) (mm) (inch) | 40515,9 | 40515,9 | 40515,9 | 40515,9 | 40515,9 |
| J | Položaj osovine pogona (mm) (inch) | 702,8 | 702,8 | 702,8 | 702,8 | 702,8 |
| K | Vertikalna dužina od osovine pogona do glave okvira (stack) (mm) (inch) | 50319,8 | 50920 | 52720,7 | 54821,6 | 56722,3 |
| L | Horizontalna dužina od osovine pogona do glave okvira (reach) (mm) (inch) | 36214,3 | 37114,6 | 37814,9 | 38315,1 | 38715,2 |
| M | Prekoračna visina (mm) (inch) | 66226,1 | 68026,8 | 71028 | 73929,1 | 76830,2 |
| N | Širina volana (mm) (inch) | 38015 | 38015 | 40015,7 | 40015,7 | 42016,5 |
| O | Dužina lule volana (mm) (inch) | 803,1 | 803,1 | 903,5 | 1003,9 | 1104,3 |
| P | Dužina poluge pedale (mm) (inch) | 1656,5 | 1656,5 | 1706,7 | 1706,7 | 172,56,8 |
| Q | Veličina kotača | 700C | 700C | 700C | 700C | 700C |
Tehnologije
ALUXX SL Aluminum Technology
This High-Performance level, state-of-the-art aluminum material is made predominantly from 6011 alloy and delivers best-in-class strength-to-weight ratios. These framesets also feature unique welding technologies for a high-performance ride quality.
Compact Road Design
When introduced by Giant in 1990s, Compact Road revolutionized the look and feel of high-performance road bikes forever. A downward sloping toptube (from the headtube to the seattube) creates smaller front and rear triangles for a lighter, stiffer bike. It also makes it easier for riders of all sizes to have a perfect fit.
PowerCore
A massively oversized bottom-bracket/chainstay area features a fully integrated, 86-millimeter wide bottom-bracket design (92-millimeterwide for off-road bikes). Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.
Variant Seatpost
This proprietary seatpost design optimizes the balance between a lightweight and superior ride quality, with simple adjustment to enhance the total race performance of the Langma road range.
3F: Fit, Form, Function
Fit, Form, and Function — Liv’s data-driven approach to building bikes for women.
Fit: Liv analyzes data on human body dimension, muscular strength and muscular activity, then considers the type of riding the rider will be doing, to build a frame that is fine-tuned through athlete feedback cycles with the goal to fit as many women as possible.
Form: The bike’s outlook takes the form with the intention to create a strong bond between the rider and the bike. The designers match the performance level of the bike with a beautiful and inspiring outlook.
Function: The componentry of the bike is carefully selected and the composite layup is uniquely crafted to give the rider an unprecedented performance edge and comfort
