EnviLiv
Advanced Pro

6.199 €

Podjelite

From the stage race breakaway to the final criterium lap, the all-new EnviLiv is made to be out front. We’ve redesigned our signature sprinter for optimized aerodynamic performance, greater stiffness-to-weight advantage, and maximum trophies.

Ključni faktori

OPTIMIZED AERODYNAMICS

In our pursuit of maximum power and efficiency, we analyze how the bike and rider experience airflow at every speed and direction, both on the computer and in the wind tunnel. The new EnviLiv features truncated ellipse airfoil tube shapes and an all-new Contact SLR Aero cockpit, with flattened tops and deeper drops, for reduced drag and added control, and better overall aero performance.

SPRINTING EFFICIENCY

Aerodynamics are affected by many factors, two of them often seen as mutually exclusive: stiffness and weight. But the EnviLiv has found the sweet spot, with a new Advanced-grade composite frame and an Advanced SL-Grade Composite fork—resulting in 205 grams of weight savings over the previous generation.

SEAMLESS INTEGRATION

When every second matters, so does every detail. So we developed a new way to route cables through the handlebar, stem, and frame, which improves aero performance, and also makes it easier to disassemble your bike for travel and maintenance. Two aerodynamic water bottle cages flawlessly integrate with the seat tube and down tube, further reducing drag.

Istaknuto

EnviLiv Advanced Pro with interactive tooltips

Tehnologije

Advanced Composite Technology
AeroSystem Shaping Technology
PowerCore
Tubeless System
OverDrive Aero

Vodič za određivanje veličine i geometrija

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XXS
      145 cm4’9”  to 157 cm5’2”
  • XS
      152 cm5’0”  to 163 cm5’4”
  • S
      158 cm5’2”  to 169 cm5’7”
  • M
      164 cm5’5”  to 176 cm5’9”
  • L
      170 cm5’7”  to 182 cm6’0”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  XXSXSSML
ADužina cijevi sjedala (mm) (inch)44017,347018,550019,753020,956022
BKut cijevi sjedala (degrees)75,0°75,0°74,5°74,0°73,5°
CDužina gornje cijevi (mm) (inch)49819,65082052420,654021,355521,9
DDužina prednje cijevi (mm) (inch)1054,11204,71355,31556,11756,9
EKut vilice (degrees)70,0°71,0°72,0°72,5°72,5°
FZakrivljenost vilice (offset) (mm) (inch)491,9491,9491,9491,9491,9
GStaza (mm) (inch)732,9662,6602,4572,2572,2
HMeđuosovinski razmak kotača (mm) (inch)97038,297338,397738,598438,799639,2
IDužina od osovine pogona do osovine zadnjeg kotača (CS) (mm) (inch)40515,940515,940515,940515,940515,9
JPoložaj osovine pogona (mm) (inch)722,8722,8702,8702,8672,6
KVertikalna dužina od osovine pogona do glave okvira (stack) (mm) (inch)49919,651720,453220,955321,856922,4
LHorizontalna dužina od osovine pogona do glave okvira (reach) (mm) (inch)36414,337014,637714,83821538615,2
MPrekoračna visina (mm) (inch)71928,373428,975229,676830,278630,9
NŠirina volana (mm) (inch)36014,236014,23801540015,742016,5
ODužina lule volana (mm) (inch)803,1803,1903,51003,91104,3
PDužina poluge pedale (mm) (inch)1656,51656,51706,71706,7172,56,8
QVeličina kotača 700C700C700C700C700C
Specifikacije
  • Veličine
    XXS, XS, S, M, L
  • Boje
    Carbon/Iris
  • Okvir
    Advanced-Grade Composite, 12x142mm thru-axle, Disc
  • Vilica
    Advanced SL-Grade Composite, full-composite OverDrive Aero steerer, 12x100mm, Disc
  • Amortizer
    N/A
  • Volan
    Liv Contact SLR Aero, 31.8mm XXS: 36cm, XS: 36cm, S: 38cm, M: 40cm, L: 42cm
  • Grips
    Liv All Condition
  • Lula volana
    Giant Contact SLR Aero XXS: 80mm, XS: 80mm, S: 90mm, M: 100mm, L: 110mm
  • Cijev sjedala
    Giant Vector, composite XXS: 350mm, XS: 350mm, S: 350mm, M: 350mm, L: 350mm
  • Sjedalo
    Liv Alcara SLR
  • Pedale
    N/A
  • Ručice mjenjača
    Shimano Ultegra Di2 ST-R8170
  • Prednji mjenjač
    Shimano Ultegra Di2 FD-R8150
  • Stražnji mjenjač
    Shimano Ultegra Di2 FD-R8150
  • Kočnice
    Shimano Ultegra hydraulic, Shimano rotors [F]160mm, [R]140mm
  • Ručice kočnica
    Shimano Ultegra hydraulic
  • Kazeta
    Shimano Ultegra, 12-speed, 11x30
  • Lanac
    KMC X12
  • Pogon
    Shimano Ultegra, 36/52 with Giant Power Pro power meter XXS: 165mm, XS: 165mm, S: 170mm, M: 170mm, L: 172.5mm
  • Osovina pogona (BB)
    Shimano, press fit
  • Obruči
    Giant SLR 1 50 Carbon Disc WheelSystem, [F] 50mm, [R] 50mm
  • Nabe
    [F] Giant Low Friction Hub, CenterLock, 12mm thru-axle [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle
  • Žbice
    SAPIM CX-Ray
  • Gume
    CADEX Race, tubeless, 700x25c (26.5mm), folding
  • Dodaci
    computer mount, two bottle cages, tubeless prepared, 30mm max tire size
  • Težina
    Koliko je težak ovaj bicikl? To je vrlo često i dobro pitanje. Ali, istina je, da zapravo nema pravog industrijskog standarda za definiranje težine bicikla te upravo zbog toga dolazi do raznih dezinformacija. Razlike postoje zbog različitih veličina okvira, materijala okvira, završne obrade i ostalih komponenti. Što je bicikl lakši to su ove razlike važnije. U GIANTu vjerujemo da je jedini ispravan način da saznate točnu težinu bicikla da ga izvažete kod vašeg prodavača bicikala.

Sve navedene specifikacije podložne su promjeni bez prethodne najave.

Sve navedene specifikacije podložne su promjeni bez prethodne najave.

}
