Avail AR 2

£1,399

Similar Products

:

Avail AR 3

£1,099

Whether it’s navigating asphalt or venturing through an unpaved short cut, the Avail AR is smooth on flats, spry on climbs and confident on descents.

Key Performance Factors

Comfort

The lightweight ALUXX aluminum frame features the latest endurance geometry with an Advanced-grade composite fork and D-Fuse seatpost to diminish vibrations.

Control

The 32c tires provide stability on both road and off-road surfaces, with compatibility for tubeless tires up to 38c. The OverDrive steerer and powerful disc brakes ensure precise handling and reliable stopping power, giving you confidence on any terrain.

Carrying Capacity

Equipped with frame mounts for racks and fenders, the Avail AR ensures you're ready for longer journeys with all the necessary gear and protection.

Techs & Features

ALUXX Aluminium Technology
Compact Road Design
D-Fuse Seatpost
OverDrive
Tubeless System

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XS
      153 cm5’0”  to 162 cm5’4”
  • S
      158 cm5’2”  to 169 cm5’7”
  • M
      165 cm5’5”  to 174 cm5’9”
  • L
      171 cm5’7”  to 182 cm6’0”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
 XSSML
A Seat Tube Length (mm) (inch)43016.946518.350019.753521.1
B Seat Tube Angle (degrees)75.0°74.5°74.0°74.0°
C Top Tube Length (mm) (inch)51520.352520.754021.355521.9
D Head Tube Length (mm) (inch)1355.31505.91706.71907.5
E Head Tube Angle (degrees)70.5°72.0°72.0°72.0°
F Fork Rake (mm) (inch)451.8451.8451.8451.8
G Trail (mm) (inch)732.963.52.563.52.563.52.5
H Wheelbase (mm) (inch)99839.399039100039.4101640
I Chain Stay Length (mm) (inch)42016.542016.542016.542016.5
J Bottom Bracket Drop (mm) (inch)702.8702.8702.8702.8
K Stack (mm) (inch)53020.955021.756922.458823.1
L Reach (mm) (inch)37214.637214.637714.838615.2
M Stand Over Height (mm) (inch)6872771628.274429.377230.4
N Handlebar Width (mm) (inch)3801540015.740015.742016.5
O Stem Length (mm) (inch)702.8803.1903.5903.5
P Crank Length (mm) (inch)1656.51656.51706.7172.56.8
Specs
  • Sizes
    XS, S, M, L
  • Colours
    Lavender Blush
  • Frame
    ALUXX-grade aluminum, 12x142mm thru-axle, disc
  • Fork
    Advanced-grade composite, full-composite OverDrive steerer, 12x100mm, disc
  • Shock
    N/A
  • Handlebar
    Liv Connect, 31.8mm, XXS: 380mm, XS: 380mm, S: 400mm, M: 400mm, L: 420mm
  • Grips
    Liv All Condition
  • Stem
    Giant Sport, XXS: 70mm, XS: 70mm, S: 80mm, M: 90mm, L: 90mm
  • Seatpost
    Giant D-Fuse, composite, XXS: 350mm, XS: 350mm, S: 350mm, M: 350mm, L: 350mm
  • Saddle
    Liv Approach
  • Pedals
    PEDALS NOT SUPPLIED
  • Shifters
    Shimano Tiagra 2x10
  • Front Derailleur
    Shimano Tiagra
  • Rear Derailleur
    Shimano Tiagra
  • Brakes
    Shimano Tiagra hydraulic discs, Giant MPH rotors [F]160mm, [R]160mm
  • Brake Levers
    Shimano Tiagra
  • Cassette
    Shimano HG500 10x34
  • Chain
    KMC X10
  • Crankset
    Shimano Tiagra 34/50
  • Bottom Bracket
    Shimano BB-RS500
  • Rims
    Giant S-R2 Disc
  • Hubs
    Giant alloy, 12mm thru-axle
  • Spokes
    stainless
  • Tyres
    Giant Gavia Fondo 2, 700x32c, tubeless
  • Extras
    tubeless prepared, 38mm max tire size
  • Max Tyre Clearance
    38mm
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Every effort has been made to ensure accuracy throughout this website. However, Giant reserves the right to change bike specifications, features, prices and colours without prior notice.
