Devote Advanced Pro

Mikä on kokoni?

Share

From bikepacking and gravel grinders to everyday adventure rides and group trekking, Devote Advanced has what it takes to stir your backcountry desires.

Key Performance Factors

Lightweight

Advanced-Grade Composite frame and fork keeps your ride lightweight so you can sail up climbs and accelerate quickly on paved or gravel roads.

Adventure-Ready

With clearance for 45c tires and mounts for racks, accessories and three water bottle cages, this bike meets the demands of your next epic ride.

Smooth Operator

Internal cable routing and D-Fuse seatpost and handlebars keep this gravel bike clean and contoured for vibration-damping comfort and less maintenance.

Specs
  • Koot
    XS, S, M, L
  • Värit
    Dark Purple
  • Frame
    Advanced-Grade Composite, 12x142mm thru-axle, disc
  • Fork
    Advanced-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc
  • Shock
    N/A
  • Handlebar
    Giant Contact XR D-Fuse, 31.8 XS:40cm, S:40cm, M:42cm, L:42cm
  • Grips
    Liv All Condition
  • Stem
    Giant Contact XS:70mm, S:80mm, M:90mm, L:90mm
  • Seatpost
    Giant D-Fuse SLR, composite, -5/+15mm offset
  • Satula
    Liv Approach SL
  • Polkimet
    platform pedal
  • Shifters
    Shimano GRX RX-815 Di2, 2x11
  • Front Derailleur
    Shimano GRX RX-815 Di2
  • Rear Derailleur
    Shimano GRX RX-815 Di2
  • Jarrut
    Shimano GRX RX-810 hydraulic, Shimano SM-RT800 rotors [F]160mm, [R]160mm
  • Brake Levers
    Shimano GRX RX-810 hydraulic
  • Cassette
    Shimano CS-HG800, 11-speed, 11x34
  • Chain
    KMC X11SL-1
  • Crankset
    Shimano GRX RX-810, 31/48 XS:170mm, S:170mm, M:172.5mm, L:172.5mm
  • Bottom Bracket
    Shimano, press fit
  • Rims
    Giant CXR-1 Carbon Disc WheelSystem
  • Hubs
    Giant CXR-1 Carbon Disc WheelSystem
  • Spokes
    Giant CXR-1 Carbon Disc WheelSystem
  • Tires
    Maxxis Receptor, 700x40c, tubeless
  • Extras
    tubeless prepared, 50mm max tire size
  • Weight
    Tarkin tapa määrittää minkä tahansa pyörän paino on pyytää paikallista jälleenmyyjääsi punnitsemaan pyörä puolestasi. Monet merkit pyrkivät ilmoittamaan mahdollisimman alhaisen painon, mutta todellisuudessa paino voi vaihdella koon, viimeistelyn, laitteiston ja lisävarusteiden mukaan. Kaikki pyörämme on suunniteltu luokkansa parhaaseen paino- ja ajo-ominaisuuksiin.

All specifications and prices listed are subject to change without notice.

Highlights

Devote Advanced with interactive tooltips

Sizing Guide and Geometry

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  • XS
      150 cm4’11”  to 163 cm5’4”
  • S
      158 cm5’2”  to 169 cm5’7”
  • M
      164 cm5’5”  to 175 cm5’9”
  • L
      170 cm5’7”  to 181 cm5’11”
bike diagram with measurements referenced in table that follows
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
  XSSML
ASeat Tube Length (mm) (inch)39015,442016,546518,350019,7
BSeat Tube Angle (degrees)75,0°75,0°74,5°74,5°
CTop Tube Length (mm) (inch)51520,352520,753521,155021,7
DHead Tube Length (mm) (inch)953,71254,91556,11807,1
EHead Tube Angle (degrees)70,5°70,5°71,0°71,0°
FFork Rake (mm) (inch)502502502502
GTrail (mm) (inch)75,9375,9372,52,872,52,8
HWheelbase (mm) (inch)101339,9102040,2102240,2103940,9
IChain Stay Length (mm) (inch)43016,943016,943016,943016,9
JBottom Bracket Drop (mm) (inch)803,1803,1803,1803,1
KStack (mm) (inch)53020,95582258823,161224,1
LReach (mm) (inch)37814,937614,837214,638015
LReachToHandlebar (mm) (inch)42916,943717,244317,445217,8
MStand Over Height (mm) (inch)68326,97112874929,577930,7
NHandlebar Width (mm) (inch)40015,740015,742016,542016,5
OStem Length (mm) (inch)702,8803,1903,5903,5
PCrank Length (mm) (inch)1656,51706,7172,56,8172,56,8
QWheel Size 700c700c700c700c

Techs & Features

Advanced Composite Technology
Compact Road Design
D-Fuse Seatpost
OverDrive
PowerCore
Tubeless System
MegaDrive
