Avow's frame geometry is designed from the ground up to help women achieve the highest level of performance, while no-compromise components and women's-specific contact points ensure comfort where women need it most
{{ item.Quote }}
Avow
Advanced Pro 2
PERFECT FIT, EASE OF ADJUSTMENT AND AERODYNAMICS CREATE AN UNSTOPPABLE TRIFECTA IN THE WORLD’S FIRST TRULY WOMEN’S-SPECIFIC PERFORMANCE TRIATHLON BIKE.
Key Performance Factors
Comfort
Liv’s 3F Design Philosophy and purpose driven design, along with the Advanced Composite frame technology, create a comfortably tuned tri bike for women.
Built for Endurance
An array of body-positioning options conserve energy in key muscle groups for other tri stages.
Absolutely Aerodynamic
From the aero frame design to the wheels, fork, and base bar, Avow cheats wind resistance for top speed and performance.
Why We Love It
The lightweight frame is handcrafted using AeroSystem Shaping Technology and features an Advanced-grade composite layup tuned for the female rider. Along with Liv’s 3F Design Philosophy, the Avow Advanced Pro uses the latest aerodynamic and fit technologies, for comfortable touch points and versatile positioning that allow you to ride longer with ease. The AeroVault System keeps all the essentials in reach by integrating hydration and storage into the bike. With an aerodynamic wheel set, base bar, and AeroDrive fork, the Avow Advanced Pro is the perfect choice for the top performing triathlete.
Highlights
Techs & Features
Advanced Composite Technology
Liv’s High-Performance Grade raw carbon material is used to produce this frameset in our own composite factory. Using state-of-the-art materials and manufacturing techniques, Liv’s Advanced-Grade Composite frames are designed to offer light weight and stiffness with optimal compliance.
OverDrive
Designed to provide precise front-end steering performance, this fork steerer tube technology uses oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
AeroSystem Shaping Technology
Tubing shapes engineered using computational fluid dynamics (CFD) and wind-tunnel data to optimize each tube shape for superior aerodynamic performance.
PowerCore
A massively oversized bottom-bracket/chainstay area features a fully integrated, 86-millimeter wide bottom-bracket design (92-millimeterwide for off-road bikes). Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.
Tubeless System
Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.
Sizing Guide and Geometry
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
- XS
- 154 cm5’1”
167 cm5’6”
- S
- 160 cm5’3” 173 cm5’8”
- M
- 167 cm5’6” 180 cm5’11”
| XS | S | M | ||
|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 48018,9 | 51020,1 | 53020,9 |
| B | Seat Tube Angle (degrees) | 77,0° | 77,0° | 77,0° |
| C | Top Tube Length (mm) (inch) | 50019,7 | 51520,3 | 54021,3 |
| D | Head Tube Length (mm) (inch) | 803,1 | 953,7 | 1254,9 |
| E | Head Tube Angle (degrees) | 72,0° | 72,5° | 72,5° |
| F | Fork Rake (mm) (inch) | 401,6 | 401,6 | 401,6 |
| G | Trail (mm) (inch) | 682,7 | 642,5 | 642,5 |
| H | Wheelbase (mm) (inch) | 96137,8 | 97438,3 | 100139,4 |
| I | Chain Stay Length (mm) (inch) | 40515,9 | 40515,9 | 40515,9 |
| J | Bottom Bracket Drop (mm) (inch) | 753 | 753 | 753 |
| K | Stack (mm) (inch) | 49019,3 | 50419,8 | 53421 |
| L | Reach (mm) (inch) | 38715,2 | 39815,7 | 41716,4 |
| M | Stand Over Height (mm) (inch) | 74029,1 | 76730,2 | 78831 |
| N | Handlebar Width (mm) (inch) | 40015,7 | 40015,7 | 40015,7 |
| O | Stem Length (mm) (inch) | 803,1 | 803,1 | 803,1 |
| P | Crank Length (mm) (inch) | 1656,5 | 1656,5 | 1656,5 |
| Q | Wheel Size | 700C | 700C | 700C |
